FOX FLOAT 3 EVOL RC2 Front Shock Kit – Black (830-24-237 / 535-9432)

Transform your ride’s handling with the FOX FLOAT 3 EVOL RC2 front shock kit. Engineered for sport and race ATV applications, these ultra-lightweight, air-spring shocks deliver precision damping, Kashima-coated durability, and fully tunable compression and rebound. Each shock provides a plush yet controlled ride with race-proven performance — shedding up to six pounds over coil-spring setups.

✅ What’s Included

• (2) FOX FLOAT 3 EVOL RC2 Front Shocks – black anodized finish

• Integrated EVOL & MAIN air chambers

• External rebound adjusters

• High- & low-speed compression adjusters

• 6061-T6 aluminum piggyback bodies and reservoirs

• Aerospace-grade PTFE spherical bearings

• User setup guide & tuning chart

📦 Fitment

• Yamaha YFZ450 (2004 – 2008 incl. SE & Bill Balance Edition)

• Yamaha Raptor 700 / Raptor 700R / Raptor SE (2006 – 2018)

• Yamaha Raptor 660R (2001 – 2005)

• Direct bolt-on for OEM A-arms and aftermarket setups (Lone Star +2 A-arms compatible)

• Shock length: 17.6″ (447 mm) eye-to-eye

🛡️ Warranty Info

• Limited Lifetime Warranty (original owner, non-transferable)

• Rebuildable & serviceable through any authorized FOX center

🔑 Key Features

• Dual-chamber EVOL air system for fine-tuning ride height & bottom-out resistance

• External rebound & dual compression adjustability

• Chrome-silicon negative spring for smoother stutter-bump compliance

• Velocity-sensitive valving for consistent damping across terrain

• Kashima-coated bodies for ultra-low friction and long-term wear resistance

• Samurai Sealing System keeps mud & debris out for long service life

• Lightweight design (≈ 4.4 lb each) – reduces unsprung mass, improves response

• Built in the USA to race-spec tolerances

💲 Price & SKU

Retail Price: $1,599.99
SKU / Part Number: 535-9432 (Brand # 830-24-237)
UPC: 711745591745
Weight: 13 lbs | Package Dims: 31 × 13 × 6 in
Availability: In Stock – Ships Next Business Day
